Stone Fruit Puree Processing Production Line

Applicable Stone Fruit Types: Peach, apricot, plum, cherry, mango and other stone fruits, as well as olive and similar hard-pit fruits.

Final Products:

Pure stone fruit puree for direct consumption.
Flavored stone fruit puree, such as honey peach puree.
Bakery fillings such as apricot puree.
Jam and fruit spread base materials.
Beverage-grade fruit puree additives.

Process Flow

Raw Material Preparation:
Sorting to remove insect-damaged and spoiled fruits → Air-bubble washing with citric acid color protection → Hot blanching for peeling → Mechanical pitting with a pitting rate ≥98%

Puree Processing Core:
Low-temperature pulping at 50–60 °C to preserve natural fruit aroma → Filtration through a 150-mesh screen to remove pit fragments and pulp residues → Optional flavor formulation

Sterilization and Freshness Preservation:
Pasteurization at 80–85 °C for 20–30 seconds → Vacuum deaeration to prevent oxidation and phase separation

Precise Pitting Performance Dedicated pitting equipment adjustable to different fruit sizes.
Complete separation of hard pits with fruit flesh loss ≤5%.

Precise Pitting Performance

Color Protection and Freshness Retention

Hygienic and Safe Design

Flexible Processing Capability

Single Machine Recommendation

Case
Showcase
01 / 03
  • Case Showcase
    Focus on liquid food processing tanks and customize reliable solutions. Food-Grade Precision Engineering, Built for Safety & Efficiency.
Why Choose Yiyang
  • Deep understanding of craftsmanship
    The team is familiar with the HACCP key control point requirements for dairy processing.
  • Truly food-grade manufacturing
    The entire process from material certification to inner surface polishing (Ra ≤ 0.6 μ m) is traceable.
  • Modular and flexible design
    The equipment is convenient for future capacity upgrades or process adjustments.
  • Turnkey service capability
    From planning, manufacturing, installation, to debugging and training, clear responsibilities and ease of use.
Don't see your industry?
Whether you are planning to build a complete production line or need to upgrade existing equipment, we can provide you with professional consultation and solutions.
